Laser Vision System (LVS)

DESIGNED BY: Young Solutions Inc.

When we first started this project, and we were brainstorming what it would look like the customer said “Can you do that? Is it possible?” We felt just like Walt: “It’s kind of fun to do the impossible.” – Walt Disney.

Features or Advantages

• State of the art Laser Vision System technology for non-contact measurement of critical parts
• Provides real time measurements as the laser beam traverses across the surface
• Integrated PC Software and Control
• The unit runs from the touch screen, or an adjacent connected PC.
• Results are automatically stored in a database. This is useful when performing analysis later
• Zoom Video Magnification SystemAll Electric Operation – No air hoses are needed! Eliminate condensation, contamination, and air supply problems.
• Part images are captured and linked directly to inspection records via powerful database software.
• The system is mounted on an articulating arm to provide multiple functions including:
• Use with the integrated machine
• Zoom magnification that requires no refocus
• The ability to video, or take still pictures of virtually anything; and subsequent email capabilities
• USB Connectivity
• There are no special personal computer requirements
• Flexible This unit handles multiple part sizes with a few simple adjustments
• Measures to 1 Micron
